SSP E7 LABOUR DELIVERY ROOM BED (ELECTRIC)

Model: SSP E7

Description:

  • Advance Liner actuator system with IP54 Liquid splash protection (03 pcs. Motor, 01 pcs. Control box, 01 pcs. Handset)
  • PP Head Panels with metal inserts along with lock and corner buffer.
  • PP Moulded Two Pieces individual Side Rails.
  • Tubular framework mounted on 125mm (5") Central locking castors.
  • Three-section top made of Bakelite sheet covered with 3 section
  • Removable suitable Mattress.
  • Positions Obtained/Function's by Patient Hand Remote: Backrest,
  • Hi-Low, Trendelenburg & Reverse Trendelenburg.
  • Leg end section can slide under the main section. Height adjustable a pair of foam padded knee crutches.
  • S.S Telescopic I.V. Rod with 4 hooks
  • Detachable S.S. Tray
  • Provided with adjustable S.S. Grip Handles on both sides.
  • Finish: Pretreated and epoxy powder coated.

Dimensions:

Overall Dimension (LxW) - 2090x1000mm
Mattress Platform (LxW) - 1EWEDS900x660mm
Backrest - 80°
Trendelenburg - 14°
Reverse Trendelenburg - 6°
Height-620mm - 900mm
Safe working Load -180kgs
Patient Weight bearing capacity - 150kgs
Castors -125mm Central
Power - 110VAC-240VAC, 50/60Hz
Electrical Shock protection - Class 1, Type B
Liquid ingress Protection - IPX6
Safety Standards - IEC60601-2-52, IEC60601-1-1, IEC60601-1-2
