INFANT RADIANT WARMER (MODEL: SSP IRW 102)

Model: SSP IRW 102

Range of SSP IRW 102 Intant Radiant Warmer allow you to efficiently care and provide advance warming capabilities while using ong touch operations to simplify procedures. Advance micro processor controlled system with self-check on the electronic circuitry skin/air/manual control Control Panel The SSPIRW 102 intant Radiant Warmer comes with automatic manual and baby (Servo) modes. In addition, the Skin/Air. temperature display is larger than other set temperature display. Skin temperature display can be converted from "C to "F by the push of a button. A big LCD is provided for more information and visualizations of the heater power in manual and servo modes. A full complement of alarms provides safety and convenience with both audible and visual indicatorsin the event of.

Power Failure

Skin High

Skin Low

Power Fail

Heater Fail

Manual Mode :

Facility of converting the warmer from servo mode to manust mode for non-stop working of the unit.

Baby Bed :

The spacious baby bed incorporates easy drop down/ fold down glasses for maximum access to the patient. Optional: X-Ray facility is provided below the baby bed for taking X-ray of the baby without disturbing.

Dimensions Technical Specification complain

Height:  1850mm
Length: 1050mm
Width:    650mm

Electrical specification (IEC)

Power supply:   200V/50Hz
Haster Power:   650 Watts
Fuse:                 5Amp

Heater Assembly :

The heater assembly located above the centre of the support structure consists of an integral examination light and a 650 watts heating system (silica or quartz/ Ceramic Heater) for quick warming and even distribution of heat on the baby bed. The heater can be swivelled in either direction for taking x-ray and doing procedures.

Highlight of The Product:

The unit is designed in such a way that the main control system can be swivelled to the side for access from all the four sides to the patient in critical condition. Option: weighing scale.

Castors :

The system is fitted with " high quality castors having brakes in front 2 castors, Antistatic castors (Optional).
